LISTA DE PIEZAS DE CS150B
9
Ref. # Description National Nail Item #
414* SPRING A 0138549
415 C - RING 0138550
416 MOUNTING BRACKET 0138551
417 HEX.SOC.HD.BOLT 0138552
418 ANCHOR BLOCK 0138553
419* BRACKET A 0138554
420 BOLT ASSY 0138555
421 BOLT W/FLAT WASHER 0138556
422 HEX.SOC.HD.BOLT 0138557
423 E - RING 0138558
424 SNAP RING 0138559
425 DOOR LATCH COVER 0138560
426 LATCH SPRING 0138561
427 DOOR LATCH 0138562
428 FOLLOWER 0138563
429 PUSHER CUSHION 0138564
430 BRACKET B 0138565
431* TRACK 0138566
432 HEX.SOC.HD.BOLT 0138567
433* HALF ROUND HD.HEX.BOLT 0138568
434* HOLD DOWN SPRING 0138569
435* PUSHING 0138570
436 PIN FEED PISTON 0138571
437 O - RING 0138572
438* SPRING 0138573
439 FEEDING TRACK 0138574
440* INLET TUBING 0138575
441* BARB FITTING 0138576
442 O - RING 0138577
443 FEED PISTON 0138578
444 O - RING 0138579
445* SPRING FEED 0138580
446 FEED BUMPER 0138581
447 FEED PISTON CAP 0138582
448 C - RING 0138583
449 MAG. COVER LEFT 0138584
450 PHILLIPS SCREW 0138585
451 LOCK NUT 0138586
452 MAG. COVER RIGHT 0138587
453 DOOR 0138588
454* TRIGGER PIVOT PIN 0138589
455* SAFETY A UNIT 0138590
456* ADJUST AXIE 0138591
457* SAFETY B 0138592
458* RING 0138593
459* SPRING 0138594
460* SAFETY GUIDE 0138595
461 LOCK NUT 0138596
462 HEX.SOC.HD.BOLT 0138597
O-Ring Kit (contains parts in
bold)
0138642
* Indica partes
que son
comúnmente
reemplazadas
