Stinger SPX350X2 - SPX1000 X5 Specifications; RMS Power Output; Recommended Load

Amplier Owner’s Manual
© 2019 Stinger • www.stingerelectronics.com
Specications
SPX1000X5
5 Channel Power Amplier
Frequency Response: ± 1dB from 20Hz to 20kHz
Signal to Noise Ratio: >110dB
High and Low Pass Crossovers: 12dB per Octave
Low Pass Crossover Range: 40Hz to 400Hz
High Pass Crossover Range: 40Hz to 400Hz
Sub Crossover Range: 50Hz to 250Hz
Input Range: 200 millivolts to 12 volts
Typical Efciency: 80%
Damping Factor: Greater than 200
Recommended Fuse Size: 80 amp
Power/Ground Wire Size: 8 Gauge
Dimensions: 215mm L x 130mm W x 41mm H
8.5” L x 5.11” W x 1.6” H
RMS Power (14.4Vdc ≤1% THD):
95 x 4 @ 4 ohm Stereo - CH 1-4
275 x 1 @ 4 ohm - CH 5
150 x 4 @ 2 ohm Stereo - CH 1-4
500 x 1 @ 2 ohm - CH 5
Lowest Recommended Load:
4 ohm Bridged or 2 ohm Stereo
11.85in/300.9mm
5.11in/130mm
1.6in
41mm
11.16in/283.5mm
