V-2
2 Channel Power Amplifier
2 채널 파워 앰플리파이어
Table Of Contents / 목 차
1
Introduction / 제품 소개.....................................................................
2-3
2
Important Safety Instructions / 안전을 위한 주의 사항..................
3-4
3
Warranty Information / 제품 보증에 대해서.....................................
5 a,b
4
Panel Description / 각 부의 명칭......................................................
6-8
5
Connecting Your System / 올바른 설치 방법..................................
9-13
6
System Hookup Diagram / 시스템 연결 구성도...............................
14-16
7
Block Diagram /
회로의 구성도............................................................
17
8
Specifications /
제품 규격...................................................................
18
Ⅰ Introduction / 제품 소개
The STK V-2 is a high quality, stereo power amplifier featuring state-of-the-art performance
designed for professional sound reinforcement and installation use. The V-2 can also be used
as a monophonic amplifier by setting bottom panel switch to the mono/bridge position.
The V-2 features oversized skive fin stock type heat sinks for efficient convection cooling.
In addition, the V-2 has a heavy duty aluminum rack handles which adds thermal efficiency.
A full complement of LED indicators monitor functions and performance conditions.
While providing powerful, accurate and reliable performance along with outstanding value,
your STK V-2 power amplifier has been designed for many years of dependable service.
Please take the time to read this manual before operation so that you fully understand the
features and correct use of this exceptional product.
