Storm Shell 55 - Tools and Hardware Requirements; Tools and Hardware Identification

4
Tools Required
 Phillips head screw driver or electric drill
 13mm Socket and Wrench
 Bubble Level
 Electric drill, ¼” drill bit for mounting holes
55/65 Storm Shell Pole Mount Hardware:
ITEM
NAME
QUANTITY
L1
1.5” U-Bolt
2
L2
2.0” U-Bolt
2
L3
3.0” U-Bolt
2
L4
4.0” U-Bolt
2
L5
M6 x 16mm Bolt
4
L6
M8 x 30mm Bolt
4
L7
M6 Nut
4
L8
M8 Nut
8
L9
Flat washer D8
8
L10
Spring washer D8
8
