INSTALLATION INSTRUCTIONS RANGE ELECTRIC
Fitting the plinth (if applicable)
• Ensure the appliance is raised to a
height of 915mm or above using
adjustingfeet(A)beforebeginning.
• Open the appliance doors and loosen
screw(C),donotremovethescrew
entirely. If your appliance has a stor-
age drawer at the bottom, you access
thescrews through holes located at
the base of the drawer after lifting
the mat.
• Fitplinth(B)andsecureusingscrew
(C).
Fitting the splashback (if applicable)
• LooselytscrewAandnutBinto
hole 1 at both ends of the rear sur-
face of the appliance.
• LocatettedscrewAthroughthe
slots in both of the metal splashback
plates.
• Tighten screw A and nut B.
• Now locate and tighten screw C and
nutDthroughhole(2)atbothends
of the rear surface of the appliance.
Make sure that the splashback is
securely attached, but avoid over
tightening.
Fitting the towel rail (if applicable)
• On the towel rail there are two hole,
top(A)andbottom(B),theseholes
have corresponding holes on the
fascia at each end.
• Thescrewforthetophole(A),must
be screwed into the supplied adaptor,
where as the remaining screw just
goesthroughthebottomhole(B).
Both screws are M6 screws. Using
the allen key provided, tighten the
screws making sure that the towel
railisushtothefascia,butnot
over tightened.
A
B
(1)
(2)
A
B
C
D
DOOR
PLINTH
OVEN CAVITY
B
A
C
