7
1. Fixing the wall bracket. Fixing the wall bracket to the wall by 2cm-15cm over the shaft or
intermediate bracket (depend on the actual installation space).
2. Fixing the steel track to the wall bracket with axis pin. (Fig. 8)
3. Fix the U bracket as closer to the opener as you can by butterfly shape screw, if there is
enough space.
4. Fixing the ET hanging bracket and the ceiling bracket.
Notice: Make sure the track is horizontal and vertical to the shaft. Make sure the
connection of ceiling bracket and ceiling is firm enough.
5. Fixing the door bracket on the door panel. (Fig. 9)
6. Fixing the straight arm and bent arm. (Fig. 9)
7. Fix the clutch cord.
8. Release the clutch, try to open and close the door by hand. Make sure there is no
resistance between door panel and track.
9. Connecting the opener with power and adjusting the operation.
Notice: Make sure the opener’s voltage is in accordance with the local voltage. Connect
the opener to a properly earthed power supply.
