7
TECHNICAL DATA
TECHNICAL DATA
Stratford
EB 7
Stratford
EB 9
Stratford
EB 12
Stratford
EB 18
Nominal output to room (kW) 3 4.5 6 9
Output to Water - Multi (kW / BTU) 7 / 24,000 8.86 / 30,700 12 / 41,200 18 / 61,146
Output to Water - Wood (kW / BTU) 5 / 18,000 6.75 / 23,025 9 / 30,900 13.5 / 45,860
Efficiency Net. (%) 60.83 67.00 71.00 72.83
Mean Co Emission @ 13% O2 (%) 0.62 0.64 0.78 0.89
Mean Flue Gas Temperature °C 295 328 413 479
Minimum Distance to Combustible materials (mm)
Overall height 570 570 603
659
Overall Width 489 489 561 615
Overall depth 417 417 412
402
Height to centre of rear flue 431 431 442
501
Depth from back to centre of top flue N/A 144 149 147
Flue diameter (mm / inch) 101 / 4” 101 /4 ” 127 / 5” 127 / 5”
Weight packed (Kg)
109
112 119 127
1 Kw = 3420 BTU, 1 inch = 25.4mm
Stratford EcoBoiler Stove
Stove Data Plate:
Arada Stove Data Plate
Information
Arada stoves are fitted with a data plate
located on the bottom right hand side of the
stove, just below the riddling shaft as shown
in fig. a
The data contained is as indicated in the
table above.
Fig. a
Side = 110
Rear = 130
Side = 120
Rear = 140
Side = 130
Rear = 150
Side = 140
Rear = 160
