OSD
Locating, alarm, license plate, speed and date/time
Operation Interface
Graphical user interface
Recording
Video/Audio Compression
Video:H.265/H.264
Audio: ADPCM, G.711U
Image Resolution
PAL:
1080P,720P,WD1(928X576),WHD1(928X288),
WCIF(464X288),D1(704X576),HD1(704x288),
CIF(352x288);
NTSC:
1080P,720P,WD1(928X480),WHD1(928X240),
WCIF(464X240),D1(704x480),HD1(704x240),
CIF(352x240);
Digital:
1080P(1920X1080),720P(1280X720).
Image Quality
8 levels adjustable (1 is the best)
Recording Mode
Boots up/schedule/alarm event recording
Pre-recording
0-60 minutes
Post-recording
0-30 minutes
Playback
Playback Channel
Local: supports 1/4/9 channels (single channel main
stream, multi-channel sub stream)
WEB: supports 1/4/9 channel synchronous playback
Search Mode
Date/time, channel, event
Network
Wire
LAN:1000M/100M(RJ45 without light)
Wireless
WIFI: supports 802.11b/g/n/ac
3G/4G: Supports one (support remote wake-up)
Locating
GPS
Location tracking, speed detection and time sync
Sensor
G- Sensor
Built-in six -axis inertia sensor
Storage
HDD/SSD
1 x3.5 "SATA HDD
Compatible with 20 ~ 26.1mm, supports hard disk heating
SD card
Supports SDXC 32GB /64GB/128GB/256GB,
Hot-plugging
Interface
USB
1 x USB2.0 (Type A) + 1 x USB2.0 (Type B)
eSATA
1 x eSATA
SD
1 x SD card slot
SIM
1 x PUSH-PUSH SIM card slot
Serial interface
2 x RS232, 2 x RS485
CAN
2 x CAN
Sensor
8 inputs, 2 outputs
Pulse Speed Detection
1 channel
Control panel
CP4
Intercommunication
One MIC port (CP4)
Power
Input
DC8-36V
Output
5V@500mA & 12V@500mA
