BATTERY INSTALLATION/ REMOVAL
The ProTac® Rail Mount uses one SL-B26® rechargeable battery or two CR123A batteries. Unscrew the tail cap and
remove depleted batteries, insert fresh batteries positive end first, replace and tighten tail cap.
SL-B26® USB BATTERY CHARGING
Fully charge battery before first use.
To charge the SL-B26® battery, insert the USB-C plug into the connector near the positive end of the battery. The
battery may be left plugged into a USB-C cable continuously, there is no danger of overcharging.
LED Charge Indicators
The SL-B26® batteries have a red/green charge indicator on the positive end.
• Charging…Red LED is on.
• Charged…Green LED is on.
Charge time is approximately 5 hours when using Streamlight AC adapters.
MOUNTING
The rail clamp is designed to rapidly and securely attach/detach from rifles, carbines and sub machine guns with a
MIL Standard 1913 or M-LOK
®
rail*.
For the 1913 rail, rotate the thumb wheel until the clamp is fully open. Slip the clamp over the 1913 rail of the weapon
and retighten the thumb wheel securely.
To use the M-LOK
®
mount, replace the
1913 rail clamp by removing the two
mounting screws using a 2mm hex wrench
and loosening the thumb wheel fully.
Align the M-LOK
®
mount holes with the ProTac® Rail Mount holes and use the 3/32” hex wrench to tighten the 8-
32x1/4” screws.
To connect the ProTac® Rail Mount and M-LOK
®
mount to the rail, rotate the M-LOK
®
T-nuts to the install/uninstall
position. Position this assembly in the desired rail location. Tighten the 10-24x3/8” screws using the 1/8” hex wrench
to lock the T-nut.
