PARTS IDENTIFICATION
PARTS LIST
The parts of the StreetStrider 8r are listed and labeled in the following table and images.
# DESCRIPTION HARDWARE SPECIFICATIONS QTY STATE
1 Main frame bone
2 Head tube
3 Cross bar, with joint #1
clamp
2.5 mm set screws M5 x P0.8 x L4 x W2.5 8 Snug but allow
clamp to swivel
4 Front beam
5 Fold joint, with silver
male cap screws and
silver female barrel nuts
6 mm hex screws:
upper and lower
middle
washers
5 mm barrel nuts
M8 x P1.25 x L30 x H13 x W6
M8 x P1.25 x L20 x H13 x W6
OD12 xID8 x T1
M8 x P1.25 x L16 x H12 x W5, barrel OD 10 mm
2
1
3
3
Tighten
Tighten
Tighten
6 Stride pole upper
8 Strider pole lower
9 Strider ski
10 Foot platform 4 mm screw under tape
10 mm lock nut
washer
M6 x P1.0 x L16 x H12 x W4, flat head
M6 x P1.0 x W10, nylon lock
OD12 x ID6 x T1
12
8
8
Tighten
Tighten
11 Seat stay
12 Chain stay
