Strida 3 - Crank & Bottom Bracket

www.strida.com
29
bottom bracket moulding 2 off
double flange front
pulley
freewheel clamp rin
g
crank axle
belt tensioner
freewheel
freewheel crush washer
crank
crank
pedal
pedal
m4 nylock nut
m4 plain washer
m8*40 bolt 2 off
m6*53 bolt 2 off
m5*16 button hex bol
t
m6 washer 4 off
crank axle bol
t
frame end cap
knuckle
top bearing
knuckle
bottom
bearing
botton tube
fabricatio
n
bb set - locknut
bb set - tab washer
bb set - bearing cone left
bb set - bearings in cage
bb set - bearing cup
bb set - bearing cup
bb set - bearings
bb set - bearing
cone right
freewheel spacer
m8 nylock nut 2 off
m6 nylock nut 2 off
crank axle bol
t
spirol pin
spirol pin
m5 nylock nut 6 off
skiffy cap
parts and upgrade kits available from www.strida.com
tip: to remove belt, use a screwdriver
crank & bottom bracket
