Strider ST4 - Installing the Fork and Front Wheel

INSTALL FORK/FRONT WHEEL
1. Remove plastic wrap from head tube
bushings (bushings are wrapped to seal in
the grease and keep the bushings in place).
2. Place cupped fork washer on the base of
fork steer tube, cupped side down (Fig 1).
3. While holding top bushing in place with
thumb and forefinger (Fig 3) slide fork up
through the head tube on frame (Fig 2)
Take care not to push out the top bushing.
Make sure head tube sits tightly on cupped
washer (Fig 4).
4. Note the position of the STRIDER
stickers on fork. They should be positioned
right side up as shown (Fig 2).
Fig 3
Fig 4
Fig 2
NOTE: Hold top bushing
Fig 1
CUPPED FORK WASHER
(CUPPED SIDE DOWN)
