9 MA_560_A4_180619_en
3
Instructions for repair and settings
ATTENTION, danger!
Observe safety and operating instructions before realizing
any maintenance and repair works.
Failure to do so may result in heavy bodily injuries.
3.1
Mounting the needle plate
ATTENTION!
Switch off machine electrically!
3.1.1
1. Switch off machine electrically, plunger is lifted
Removing the needle plate (Fig. 1)
2. Remove the needle
3. Remove set collar (1)
4. Loosen screws (2)
5. Remove needle plate carefully
3.1.2
Remount needle plate in reserved sequence, but make sure that after mounting
the set collar the movable knife moves over the counterknife easily and does
not jam.
Remounting the needle plate
