Strong Carbon Series Installation Manual

3
HARDWARE
IMAGE DESCRIPTION ITEM QUANTITY
BAG 1
Lag Bolt
(A) 8 × 63 mm 5
Lag Washer (B) 8.4 × 19 × 2 mm 5
Concrete Anchor (C) 10 × 50 mm 5
Screw (D) M6 × 20 mm 4
Screw (E) M6 × 40 mm 4
Screw (F) M8 × 20 mm 4
BAG 2
Screw (G) M8 × 40 mm 4
Screw (H) M8 × 50 mm 4
Spacer (I) 8.5 × 15 × 5 mm 4
Spacer (J) 8.5 × 17.5 × 19 mm 4
Spacer (K) 8.5 × 17.5 × 22 mm 4
BAG 3
M6 Washer (L) 6.4 × 18 × 2 mm 8
M8 Washer (M) 8.4 × 20 × 2 mm 8
Socket Wrench (N) 10 × 58 mm 1

Strong Carbon Series Specifications

General

Type	Full Motion
Color	Black
VESA Compatibility	200x100mm to 600x400mm
Extension Range	2.4" to 19.3" (60mm to 490mm)
Material	Steel
TV Size Compatibility	37" to 70"
Mounting Pattern	Universal
