Strongarm 814B - Page 2

2
!
SETUP
Visually inspect all components for shipping damage. If any shipping damage is found, nofy carrier at once. Shipping damage is NOT covered by
warranty. The carrier is responsible for all repair or replacement cost resulng from damage in shipment.
1 Take out all the parts from the wooden box.
2 Connect 4 casters (44) with Base Assembly (40) by using Nut (41), Lock Washer (42) and Flat Washer (43).
3 Connect Adaptor (48) with the piston of the pump.
4 Aach 4 Safety Pieces (S02) to the adaptor (S03) by using Bolt (S01), Washer (S04) and Wing Nut (S05).
5 Connect Chain (S26) with Plate (S03) by using Bolt (S27), Washer (S25) and Nut (S24).
6 Aach Hook (S06) with Base by Using Wing Nut (S08). And then connect the whole assembly with the plate (S03) by using Washer (S22)
and Nut (S23).
!
WARNING!
• The technician using this jack must be trained, qualied, fully familiar with safe work pracces, and have prior experience in the use of
hydraulic equipment. Lack of knowledge in any of these areas can lead to equipment damage and/or personal injury.
• Read, understand, and follow all instrucons before operang this jack.
• Inspect the jack before each use. Do not use jack if damaged, altered, modied, leaking hydraulic uid or with missing or loose components.
• Never modify or weld hydraulic equipment.
• Never li more that the rated capacity of the jack: overloading causes equipment failure and possible personal injury.
• The jack is a load liing device, not a load holding device. Once the load is raised, it must always be rmly supported with auxiliary stands.
Never work under or around a load supported only by hydraulic devices.
• Never put unbalanced or o-centre loads on the jack saddle. Use saddle adapters and saddle extenders along with straps and chains to secure
load to the saddle head. Incorrect loading can result in equipment failure.
• This jack was designed for liing transmissions only. Consult the vehicle manufacturer for the transmission's centre of balance.
• Secure the transmission to the jack’s saddle with the anchorage restraint system provided before raising or lowering the transmission.
• Use of this product is limited to the removal, installaon and transportaon in the lowered posion. Jack should only be used on a at, clean,
unobstructed concrete oor.
• Always wear safety glasses and/or other protecve equipment that meet or exceed ANSI Z87.1 and OSHA standards.
• Use the jack ONLY on hard, level surfaces capable of sustaining the load.
!
WARNING!
1. SERVICE/INSPECTION
Visual inspecon shall be performed before each use of this equipment and its adapters, checking for abnormal condions, such as cracked
welds, leaks, and damaged, loose or missing parts. This equipment shall be removed immediately from service if it is believed to have been
subjected to an abnormal or shock load and shall be inspected by a qualied repair facility. Owners and/or operators should be aware that repair
of this equipment may require specialized knowledge and facilies. It is recommended that this equipment be inspected annually by a qualied
repair facility. Defecve parts, decals, safety labels or signs should be replaced with Strongarm specied parts.
The use of shop equipment is subject to certain hazards that cannot be prevented by mechanical means, but only by exercise of intelligence, care, and
common sense. It is therefore essenal to have personnel involved in the use and operaon of equipment who are careful, competent, trained, and
qualied in the safe operaon of this equipment and its proper use when servicing motor vehicles and their components. Examples of hazards are
dropping, pping, or slipping of motor vehicles or their components caused primarily by improperly securing loads, overloading, o-centered loads,
use on other than hard level surfaces, and using equipment for a purpose for which it was not designed. Only Strongarm aachments and/or adapters
may be used on this equipment.
The owner and/or operator shall study and understand the product and safety instrucons before operang this equipment. Safety informaon shall
be emphasized and understood. If the operator is not uent in English, the product and safety instrucons shall be read to and discussed with the
operator in the operator’s nave language by the purchaser/owner or his designee, making sure that the operator comprehends their contents. A
copy of these instrucons/warnings shall be retained for future reference.
