Strongarm 814B - Parts List

6
Parts No. Descripon Qty Parts No. Descripon Qty
1 Dust ring 1 29 Washer 1
2 O-ring 1 30 Pump 1
3 U-ring 1 31 U-limited 1
4 Oil cup 1 32 Lock washer 1
5 Caster 2 33 Screw 1
6 Second piston rod 1 34 Release pedal 1
7 Retainer ring 1 35 Pin 1
8 Dust ring 1 36 Coer pin 1
9 O-ring 1 37 Washer 2
10 U-ring 1 38 Foot pedal 1
11 Round nut 1 39 Retainer ring 4
12 O-ring 1 40 Connect rod 2
13 First piston rod 1 41 Pin 2
14 Limited ring 1 42 Pin 1
15 Plunger 1 43 Legs 2
16 Screw 1 44 Nut 4
17 Steel 1 45 Lock washer 4
18 O-ring 1 46 Washer 4
19 Round nut base 1 47 Caster with brake 2
20 Washer 2 48 Washer 4
21 Oil tank 1 49 Lock washer 4
22 Pin 1 50 Bolt 4
23 Coer pin 3 51 Saddle 1
24 Handle 1 52 Screw 2
25 Handle cover 1 53 Second Limited valve 1
26 Exhaust screw 1 54 Washer 1
27 Seal ring 1 55 Spring 1
28 Ram 1 56 Steel ball 1
!
PARTS LIST
