TECHNICAL PASSPORT INSTALLATION AND MAINTENANCE INSTRUCTIONS
Model of boiler
S7 S10 S20 S40
S7
BIO
S10
BIO
S20
BIO
S40
BIO
S10
U
S20
U
S40
U
Duration of burn with one load of
pellets, h. Min. mode.
(according to laboratory tests) Max.
mode. ***
- - - -
72
14
96
24
96
24
96
24
96
24
96
24
96
24
Duration of burn with one load of coal,
h. Min. mode.
(according to laboratory tests) Max.
mode. ***
- - - -
- - - - 130
32
130
32
130
27
Length of fi rewood (cm) 35 35 45 55 35 35 45 55 35 45 55
Water amount in boiler ( l ) 15 22 40 52 15 22 40 52 22 40 52
Effi ciency (%) 86,3 86,3 86,3 86,3 86,3 86,3 86,3 86,3 86,8 86,8 86,8
Installed pressure protection valve (bar) 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5 1,5
Flue draft (Pa) 10÷20 10÷20 10÷20 10÷20 10÷20 10÷20 10÷20 10÷20 10÷20 10÷20 10÷20
Flow of heated water max. (l/h) 200 250 500 1000 200 250 500 1000 250 500 1000
Water temperature inside of boiler (
0
C) 85 85 85 85 85 85 85 85 85 85 85
Minimum width of fl ue opening (cm
2
) 150 200 250 330 150 200 250 330 200 250 330
Diameter of fl ue (mm) 160 180 180 200 160 180 180 200 180 180 200
Distance from the bottom of boiler to
fl ue (mm)
991 1413,5 1550 1549 991 1413,5 1550 1549 1494 1673,5 1664
Dimensions, (mm)
h
d
1330
450
1900
450
(1900)
2100
560
(1900)
2100
680
1330
450
1900
450
(1900)
2100
560
(1900)
2100
680
1900
450
(1900)
2100
560
(1900)
2100
680
Weight (kg) 100 185 231 315 100 185 231 315 196 246 333
*Power depends on quality of fuel. Power depends on time: at the beginning of burning
power output is higher than indicated in a table, boiler puts out the smoke that is hotter than
300
0
C, therefore raisin residues burn out, fl ue gets warmed up and draft increases (in some
models, direct channel to fl ue is opened). While fuel burns, power of boiler decreases, because
the surface of heat dissipation increases and draft decreases, but when a house becomes warm
the power is suffi cient and additional valve is opened in order to further decrease the power of
boiler.
