-14-
SPECIAL WARNING!
BECAUSE OF MOST FREQUENT USE FUNCTION OF
CHANGING THE MOVING DIRECTION FORWARD –
BACKWARD, YOU MUST HANDLE WITH THIS LEVER
CORRECTLY. WE DO THE CHANGING AS FOLLOWS (SHOWN
ON PICTURES 7,8,9 AND 10): YOU MUST REDUCE THE GAS,
PRESS THE CLUTCH LEVER AND MOVE THE LEVER FORWARD –
BACKWARD GENTLY. WHEN YOU ARE SURE, THE LEVER IS IN CORRECT
POSITION, SLOWLY RELEASE THE CLUTCH LEVER AND ADD THE GAS
WHEN NECESSARY. WHEN CHANGING THE MOVEMENT DIRECTION THE
SPEED OF THE MACHINE IS NOT CHANGED.
The correct adjustment you can check on the gearbox, where the limiter is
mounted. The limiter is adjusted correct when the gear change lever leans onto
limiter just before end position (app. 1mm). In that case we avoid burdening and
wearing out in the gearbox.
Differential lock
- it activates with pulling of the lever backwards, it should remain in this position.
You use the differential by hard work, when both wheels traction is required or
when one wheel slips (on slopes for example) (Pic. 5a, 5b)
WARNING!
A
CTIVATING OF DIFFERENTIAL LOCK WITHOUT CLUTCH IS NOT
ALLOWED WHEN THE MACHINE IS OPERATING OR WHEN FULL GAS
.
B
Y
REDUCING THE GAS YOU CAN ACTIVATE IT WITHOUT USE OF THE
CLUTCH
.
DIFFERENTIAL, BRAKES
