SYNK® 4K Wireless Transmitter Rear Panel
1
2
3
5
6
7
4
1. HUB Port Maintenance port (Stryker use only)
2. Remote 1 Connects to video source remote output 1
3. Remote 2 Connects to video source remote output 2
4. Micro USB Port Maintenance port (Stryker use only)
5. HDMI Out Connects to a primary display
6. HDMI In Connects to a digital input source
7. AC Power Inlet Connects to AC power adapter
