22..22.. SSyysstteemm CCoommppoonneennttss aanndd IInntteerrffaaccee
D
C
A
E
G
F
L
H
I
K
J
B
FFiigguurree 44 –– CCoommppoonneennttss aanndd IInntteerrffaaccee DDiiaaggrraamm
UUsseerr IInntteerrffaaccee
AA CCaasstteerr LLoocckkss — Four locks prevent
unintended rover movement.
BB QQuuiicckk RReeffeerreennccee CCaarrdd ((QQRRCC)) — Includes safety
and troubleshooting information.
CC SSeeccoonnddaarryy CCoonnttrrooll PPaanneell — Includes
buttons and a display.
DD WWoorrkk SSuurrffaaccee — Illuminated work surface
facilitates specimen collection.
EE MMaaiinn CCoonnttrrooll PPaanneell — Includes a touch-
sensitive display and a suction control dial.
FF SSppeeaakkeerr — Provides audible feedback and status.
GG SSuuccttiioonn RRaannggee IInnddiiccaattoorr — Provides
visual feedback and status.
RReeqquuiirreedd CCoommppoonneennttss
HH)) MMaanniiffoolldd — Fluid suction manifold is a
single-use, disposable device.
II)) TTuubbiinngg — Fluid suction tubing is a single-use,
disposable device.
JJ)) EEffffeeccttoorr — Suction-end effector is a single-
use disposable device.
KK)) FFiilltteerr — Fluid suction High Efficiency Particulate
Air (HEPA) filter provides air filtration of the air
evacuated from the fluid collection canister before
the air is vented.
LL)) DDoocckkeerr — Neptune 2 Docking Station
provides fluid waste transfer to facilitate
disposal.
