TThhee CCaammeerraa CCoonnssoollee
The camera console—or Camera Control Unit (CCU)—is the control center for the 1588 AIM
Camera, and it processes the video and photographic images produced during the surgical
procedure.
FFrroonntt PPaanneell
The console front panel features a touchscreen, where different menus can be accessed,
including the controls for adjusting the Light Level, Zoom Level, and White Balance, as well as
allowing the selection of Surgical Specialty settings that optimize camera performance for specific
surgical procedures. The touchscreen also allows activation of remote outputs, which are
commonly used with a Stryker digital capture console to record images and video.
See the Operation section for more detail on using the front panel.
11.. PPoowweerr SSwwiittcchh Powers the camera ON and OFF
22.. TToouucchhssccrreeeenn Allows navigation through different menus for
controlling the camera and adjusting the video
settings
33.. CCaammeerraa--CCoonnnneeccttoorr PPoorrtt Connects to the 1588 AIM Camera Head
RReeaarr PPaanneell
The console rear panel provides ports for connecting the 1588 AIM Camera to viewing and
recording equipment, such as video monitors and Stryker device control consoles.
