4
Microphone Gain:
20.
Adjusts the microphone gain in the transmit and
PA modes. This controls the gain to the extent that full talk power is
available several inches away from the microphone.
RF Gain:
21.
This control is used to reduce the gain of the RF (receive)
amplifier under strong signal conditions. For maximum receiver
sensitivity this control should be turn all the way to the right
(clockwise).
Noise Blanker / ANL Switch:
22.
When this switch is in the NB position
the noise Blanker circuits are activated. The Noise Blanker is very
effective in eliminating repetitive pulse type noise usually associated
with ignition systems. The ANL position activates both the Noise
Blanker and Automatic Noise Limiter (ANL) Circuitry.
Echo Volume:
23.
Varies the volume or number of echo repetitions. To
increase the echo volume, rotate the control clockwise.
Echo Delay:
24.
The Echo switch turn the echo on. A big advantage to
this is you can turn it off and then back on with the switch without the
need to adjust your volume & delay potentiometer. To turn the echo
off simply move the switch to the middle position.
Fin:
25.
This is the ne control for the clarier. Please refer to the function
menu section for specific options related to this control. With the
clarier in the default mode, the ne knob would be used to ne tune
your receiving frequency. In general this is typically on used on SSB.
COA:
26.
This is the coarse control for the clarier. With the clarier in
default mode, the coarse knob would be used in conjunction with the
ne knob to tune in the station you communicating with. Both knobs
increase frequency when turned clockwise and decrease when turned
counter clockwise.
Channel Selector:
27.
This control is used to select the desired transmit
and receive channel.
