Stryker TPS 5100-8 User Manual

3
Footswitch Functions
PEDALS (factory default settings)
A
Reverse Depress pedal for variable speed (up to
maximum selected on console). Hand-
piece operates in the counterclockwise
direction.
B
Forward Depress pedal for variable speed (up to
maximum selected on console). Hand-
piece operates in the clockwise direction.
PADS (factory default settings)
The activated handpiece (TPS or Endo) determines
the operation of the pads.
I LEFT PAD
Irrigation (TPS Handpieces)
a. Tap pad to enable handpiece irrigation for the
activated TPS handpiece. Irrigation flows only
while handpiece is running. Tap pad again to stop
flow.
b. Depress pad until console beeps twice.
Irrigation flows immediately prior to handpiece
operation and continues during handpiece
operation. Tap pad again to stop flow.
Oscillate (Endo Handpieces)
Tap to allow forward or reverse pedals to operate
Endo handpiece in the oscillate mode.
II CENTER PAD
Handpiece (Endo/TPS)
Tap pad to activate desired handpiece.
III RIGHT PAD
Attachment Select (TPS Handpieces)
Scrolls the console screen through a list of
attachments. Stop when you reach the attach-
ment that is assembled to the handpiece.
High/Low Speed (Endo Handpieces)
Toggles control between the high and low speed
settings selected on the console.
High Speed: Handpiece operates up to high
speed selected on console.
Low Speed: Handpiece operates up to low
speed selected on console.

Stryker TPS 5100-8 Specifications

Power

input voltage	5VDC
input current	18mA
output voltage range	2.5VDC to 4.9VDC

Protection

IP rating	IPX7

Weight and Dimensions

width	11.7 in [297 mm]
depth	9.1 in [231 mm]
height	1.9 in [48.2 mm]
weight	5.6 lbs [2.6 kg]
cord length	15 ft [457 cm]
