Mobius - User Manual
®
pg 4
STEREO
IN/OUT
PRE /
POST
OUTPUT 2INPUT 2
POWER: NEVER
plug into voltage
higher than 9VDC.
Requires at least
300mA of available
current.
Rear Panel
OUTPUTS: Use
LEFT output for
mono. RIGHT OUT
is used as output 2
if using a pre/post
configuration.
SIGNAL ROUTING
SWITCH: Choose
between standard
stereo in/out
operation or pre/
post mode. Turn to
Pre/Post section for
more details.
EXP: Connect
an expression
pedal or switch
for external tap
tempo.
MIDI: Full featured
MIDI input and output
supporting MIDI CCs,
Program changes,
etc. Consult MIDI
Specifications section
for full MIDI spec.
INPUTS: High
impedance inputs.
Use LEFT input for
mono. RIGHT IN
is used as input 2
if using a pre/post
configuration.
