STS 1600 - Terminal 4 (T4) Connections

Rev. 2.0
16
Terminal4(T4)
Number Connect Location
T4-A1 Warm-up
T4-B1 Warm-up
T4-C1 PLC-X00
T4-D1 P1-V+1
T4-E1 P1-G2
T4-F1 PLC----+/-
T4-G1 PLC----+/-
T4-H1 Not connect
T4-I1 C1-5/L3
T4-J1 C1-A2
T4-K1 Y11-1
T4-L1 T2-J2
Number Connect
T4-A2
Temperature control
T4-B2
Temperature control
T4-C2 Paper Feed Signal
T4-D2 Paper Feeding V+,PotentiometerV+
T4-E2 Paper Feeding V-
T4-F2 Potentiometer Signal
T4-G2 Potentiometer V-
T4-H2 Not connect
T4-I2 Rotary Switch
T4-J2 Emergency switch
T4-K2 Dehumidification
T4-L2 Dehumidification
