STS 1600 - Terminal 3 (T3) Connections

Rev. 2.0
15
Terminal3（T3）
A1 B1 C1 D1
A2 C2B2 D2
Number Connect Location
T3-A1 Heating Lamp-Naught wire
T3-B1 Heating Lamp-Naught wire
T3-C1 Aiifar 4c step_moto_V1---V-
T3-D1 Y5-3,Aiifar 4c step_moto_V1---V+
T3-A2 T2-J2
T3-B2 T2-I2
T3-C2 P1-G1
T3-D2 P1-V+3
