STS 1600 - Page 22

Rev. 2.0
18
PLC-Y10 DA-Y10-4
PLC-Y11 Y11-4
PLC-Y12 Y12-4
PLC-
COM5
PLC-COM6
PLC-Y13 Y13-4
PLC-Y14 PLC-Y16
PLC-Y15 Not connect
PLC-
COM6
PLC-COM5,P1-G2
PLC-Y16 PLC-Y14
PLC-Y17 Y17-4
PLC-
24V
P1-V+3
PLC-0V P1-G1
PLC-
COM
Not connect
PLC-
COM
P1-G2
PLC-
XOO
T4-C1
PLC-X01 Not connect
PLC-X02 Not connect
PLC-X03 T2-A2
PLC-X04 Not connect
PLC-X05 Not connect
PLC-X06 Not connect
PLC-X07 Not connect
PLC-X10 Not connect
PLC-X11 Not connect
PLC-X12 Not connect
PLC-X13 Not connect
PLC-
COM
Not connect
PLC-
COM
Not connect
PLC-
24V
Not connect
PLC----
+/-
T4-F1,T4-G1
