STS 1600 - Relay Configurations Y7, Y10, Y11, Y12

Rev. 2.0
19
Relay:sunction Y7
10-DD Suction Y7
4- 1+
3+ 2-
Relay:Blow Y10
10-DD Blow Y10
4- 1+
3+ 2-
Relay:Paper Y12
10-DA Paper Roller Y12
4- 1+
3+ 2-
Relay:Suction Y10
10-DA Suction Y10
2 3+
1 4-
Relay:Dehumidfication Y11
Connection Location
Y7-1 P1-V+2
Y7-2 Suction connector
Y7-3 Y10-3
Y7-4 PLC-Y7
Connection Location
DD-
Y10-1
P1-V+2
DD-
Y10-2
T2-D2
DD-
Y10-3
Y12-3,Y7-3
DD-
Y10-4
PLC-Y10
Connection Location
Y12-1 P1-AC,Y11-2
Y12-2 T2-F1
Y12-3 Y10-3,P1-V+2
Y12-4 PLC-Y12
Connection Location
DA-
Y10-1
Y11-2
DA-
Y10-2
T2-H1
DA-
Y10-3
Y13-3
DA-
Y10-4
DD-Y10-4,PLC-Y10
Connection Location
