STS 1600 - Microstep Drive (MD) Connections

Rev. 2.0
22
P2-IN T2-I2
P2-FG T2-E2
P2-G Not connect
Microstep Drive(MD)
Number Connect Location
+V P2-V+
GND P2-V-
ENA- PLC-Dedusting
ENA+ DIR+
DIR- PLC-Dedusting
DIR+ ENA+,PUL+
PUL- PLC-Dedusting
PUL+ DIR+,PLC-Dedusting
