STS 1600 - Relay Y5 (Smoke Removal); Power Supply P2

Rev. 2.0
21
40-DA Heating Y14
2 3+
1 4-
Relay:Smoke removal Y5
10-DA Smoke removal Y5
2 3+
1 4-
Power2(P2)
Power
INPUT:88-132VAC 3.0A
176-264VAC 1.5A
OUTPUT:+41V-3.0A
47-63HZ
AC
IN
FG
G
V+
V-
Number Connect Location
P2-V+ MD--+V
P2-V- MD--GND
P2-AC T2-K2
Connection Location
Y14-1 Heating Lamp--Live Wire
Y14-2 T2-L2
Y14-3 Y5-3
Y14-4 PLC-Y14
Connection Location
Y5-1 Smoke removal device
Y5-2 Y16-1
Y5-3 Y14-3,T3-D1
Y5-4 PLC-Y5
