1 MASTER VOLUME 16 PROGRAM BUTTON
2 TREBLE KNOB 17 SKIP/FAST BACKWARD BUTTON
3 BASS KNOB 18 REPEAT BUTTON
4 BALANCE KNOB 19 PLAY/PAUSE ;
BLUETOOTH PAIR BUTTON
5 FM TELESCOPIC ANTENNA 20 LIGHT SHOW / BUTTON
6 POWER INDICATOR 21 SKIP/FAST FORWARD BUTTON
7 CHARGE INDICATOR 22 DIAL POINTER
8 BT INDICATOR 23 HEADPHONE JACK
9 FM ST. INDICATOR 24 TWEETER
10 FUNCTION SWITCH 25 MULTI COLOR LIGHT SHOW LED
11 BAND SWITCH 26 WOOFER
12 AUX IN JACK 27 CD COMPARTMENT
13 TUNING KNOB 28 CARRYING HANDLE
14 LED DISPLAY 29 DC INPUT JACK
15 POWER BUTTON 30 CD DOOR LATCH
6
LOCATION OF CONTROLS
FM
88 90 92 94 96 98 100 102 104 106 108
12
3
4
5
6789 10
11 12
13
14
15 16
17 1819 20 21 22 23
