E-6
18. REPEAT ONE LED INDICATOR
19. REPEAT ALL INDICATOR
20. PROGRAM PLAYBACK LED INDICATOR
21. PLAYBACK LED INDICATOR
22. CASSETTE EJECT/FAST FORWARD BUTTON
23. CASSETTE SLOT
24. TURNTABLE SHAFT
25. TURNTABLE PLATTER
26. 45 RPM ADAPTOR
27. LIFT LEVER
28. AUTO STOP SWITCH
29. TONE ARM
30. 33/45/78 RPM SPEED SELECTOR
31. TONE ARM REST
32. AIR CIRCULATION
33. FM ANTENNA
34. AC POWER CORD
CAUTION
:
This unit should not be adjusted or repaired by anyone except qualified service personnel.
RADIO OPERATION
1. Rotate the POWER/VOLUME ON/OFF SWITCH (#5) to turn on the SB6080.
2. Rotate the FUNCTION SELECTOR (#2) to select Radio mode. The dial scale LED will
light.
3. Use the AM/FM SELECTOR (#15) to select the desired bands.
4. Adjust the TUNING KNOB (#4) to tune in the station you want to listen to.
5. Rotate the POWER/VOLUME ON/OFF SWITCH (#5) to the desired volume level.
6. When you wish to turn off the Radio, rotate the POWER/VOLUME ON/OFF SWITCH
(#5) to the OFF position.
Hints for best reception:-
- AM : The receiver has a built-in AM bar antenna. If AM reception is weak, slightly rotate
or change the position of the unit will usually improve the AM reception.
- FM : The receiver has a build-in FM ANTENNA (#33) hanging at the rear cabinet. This
wire should be totally unraveled and extended for best reception.
CD OPERATION
NOTE: THIS UNIT NOT ONLY PLAYS COMMERCIAL COMPACT DISCS BUT ALSO
SELF-COMPILED CD-RW DISCS.
PLEASE READ THIS IMPORTANT INFORMATION:
CD mechanisms used in devices like this are designed to fully read all commercial CDs.
They will also read self-compiled CD-R/CD-RW discs but it may take up to 10 seconds for
playback to start. If playback does not start, it is likely due to the quality of the CD-R/RW
disc and/or the compatibility of the CD compilation software. Manufacturer is not
responsible for the playback quality of CD-R/RW discs.
Do not attach a label or seal to either side of the CD-R/RW disc. It may cause a
malfunction.
