STUDER Innotec Xtender
Installation and operating Instructions Xtender V1.3 Page 33
Pos. Denomination Description Comments
33 U Battery Rated battery voltage (input area) See chapter 6.2.8– p.
20
34 U ACin Rated AC input voltage (input area) See chapter 6.2.3 – p.
17
35 I ACin/out Maximum current at input / output See chapter 6.2.6 - p.
19.
36 U ACout Rated output voltage Or according to {1286}
37 I Charge Maximum charger current See chapter 6.2.4 - p.
17
38 SN:xxxxxxxxxx Serial no.
39 IPxx Protection degree according to IEC 60529
