STUDER Innotec Xtender
Installation and operating Instructions Xtender V1.3 Page 36
18 Technical data
Model XTH 3000-12 XTH 5000-24 XTH 6000-48 XTH 8000-48
Inverter
Rated battery voltage 12 V 24 V 48 V 48 V
Input voltage range 9.5 - 17 V 19 - 34 V 38 - 68 V 39 - 68 V
Continuous power @ 25 °C 2500 VA 4500 VA 5000 VA 7,000 VA
Smart boost power 3000VA 5000 VA 6000 VA 8000 VA
30 minute load @ 25 °C 3000 VA 5000 VA 6000 VA 8000 VA
5 second load @ 25 °C 3 x Pcont
Maximum load Up to short-circuit
Maximum asymmetrical load Up to Pnom
Load detection (standby) 2 to 25 W
Admissible cos phi 0.1 – 1
Maximum efficiency 93% 94% 96% 96%
Open-circuit power OFF/standby/ON 1.3W/2.2W/14W 1.8W/2.5W/18W 2.2W/3W/22W 2.2W/3.8W/26 W
Output voltage Sine wave 230 Vac (+/-2%) / 180-245 Vac
Output frequency 50 Hz adjustable 45-65 Hz +/- 0.05% (quartz-controlled)
Harmonic distortion <2%
Overcharge and short-circuit Automatic disconnection then 2 startup attempts
Overheating protection Alarm prior to disconnection and automatic restart
Battery charger
6-phase battery charger Programmable I-U-Uo-equalisation-Uo(low)-U(periodic)
Adjustable charge current 0 - 160 A
0 - 140 A 0 - 100 A 0 - 120 A
Input current sharing system 1 - 50 A
Maximum input voltage 265 Vac
AC input voltage range Level of detection adjustable from 150 to 230 Vac
Admissible input frequency 45 - 65 Hz
(PFC) EN 61000-3-2
Battery control (factory value / adjustable range with RCC-02)
End of absorption by duration: 2h / 0.25 - 18 h or by current <10A / 2 - 50 A
Absorption voltage 14.4V / 9.5-18 V 28.8V / 19-36 V 57.6V / 38 - 72 V
Periodic absorption voltage - / 9.5 - 18 V - / 19 - 36 V - / 38 - 72 V
Floating voltage 13.6V / 9.5-18 V 27.2V / 19-36 V 54.4V / 38 - 72 V
Reduced maintenance voltage - / 9.5 - 18 V - / 19 - 36 V -- / 38 - 72 V
Equalisation By number of cycles ( - / - 100) or at fixed intervals ( - / 52 weeks)
End of equalisation By duration 2h / 0.25 – 10h or by current - / 5 – 50 A
Equalisation voltage - / 9.5 - 18 V - / 19-36 V - / 38 - 72 V
Low voltage disconnection 10.8V / 9.5-18 V 21.6V /19-36 V 43.2V / 38 - 72 V
Reduced floating duration - / 0 - 32 days
Periodical absorption - / 0 - 10 hours
Temperature compensation -5 / 0 to-8 mV/°C/cell (optional BTC-01)
General data
Auxiliary contacts 2 independent contacts 16 A - 250 Vac (potential-free 3 points)
Maximum transfer relay current 50 A
Maximum transfer time 0-15 ms
Weight 34 kg 40 kg 42 kg 46 kg
Dimensions: H x W x D [mm] 230x300x500
Protection degree IP20
Conformity EN 61000-6-1, EN 61000-6-3, EN 55014, EN 55022, EN 61000-3-2,
Dir. 89/336/EEC, LVD 73/23/EEC
Operating temperature range -20 to 55 °C
Ventilation Forced from 45 °C
Noise level <40 dB / <50 dB (without / with ventilation)
Warranty 2 years
Options
Battery temperature sensor: BTS-01
Remote control and programming centre for wall mounting: RCC-02
Remote control and programming centre for panel mounting: RCC-03
