STUDER Innotec Xtender
Installation and operating Instructions Xtender V1.3 Page 35
No. of
config.
Denomination / description
Units Fact.
value
Mod.
value
1298 Increment step of the adaptive low voltage method mV/cell 20
1300 Number of overloads permitted before definite stoppage -- 3
1303 Number of battery overvoltages accepted before definite stoppage -- 3
1304 Number of battery undervoltages permitted before final stop -- 3
1307 Reset voltage for adaptive correction V/cell 2.2
1309 Minimum ACin voltage to authorise charging Vac 185
1403 Period for counting battery overvoltages sec. 60
1404 Period for counting battery undervoltages sec. 0
1432 Maximum ACin voltage to switch to inverter mode Vac 270
1433 Adaptation range of the charge current according to the input
voltage
V 20
1436 Allow to exceed AC input current without opening the transfer relay y/n yes
1470 ACin voltage hysteresis for closing the transfer relay Vac 10
1485 Automatic earth-neutral connection in inverter mode y/n no
1488 Critical under voltage of the battery V/cell 1.5
1505 Delta of higher frequency accepted Hz 15
1506 Delta of lower frequency accepted Hz 5
1516 Auxiliary contact 1 deactivated by floating mode y/n yes
1517 Auxiliary contact 2 deactivated by floating mode y/n no
1527 Decrease max input limit current with AC-In voltage o/n n
1528 Delay before closing transfer relay Min. 0
1532 Kind of dynamic compensation Auto/Man Auto
To modify the configurations, please refer to the operating instructions for the RCC-02/03
remote control
