• Make sure the power supply is connected to the wall outlet
• Make sure the power supply is properly connected to the keyboard
Ke yboard does not seem to be sending MI DI not es t o my modules?
• Make sure you are not in the EDIT MODE.
• Make sure the ZONE switch of the ZONE you are trying to play is on.
• Make sure the MIDI channel you are playing on is enabled on your sound source.
• Make sure your sound modules audio outputs are connected properly to your mixer or amp.
• Make sure your mixer amp or sound system is on and the volume settings are up.
I have made changes in EDIT MODE but the changes do not seem to be present when I
return to PLAY MODE?
• This can happen very easily. When you enter EDIT MODE make sure you are editing the ZONE
• that you were playing before hitting EDIT. When entering edit mode you will be on the ZONE
• you last edit ed not necessarily t he ZONE you have on in PLAY MODE.
I know I am sending MIDI to my module because I see the MIDI indicator light up when
I play but I hear nothing?
• Make sure the VOLUME PEDAL is depressed forward to send full volume!
• Make sure your sound modules audio outputs are connected properly to your mixer or amp.
• Make sure your mixer amp or sound system is on and the volume settings are up.
Th e SU STAI N PEDAL d o e s n o t s e e m t o wo r k ?
• Make sure it is plugged in properly to the SUSTAIN PEDAL INPUT
• Make sure the SUSTAIN PEDAL is enabled for the ZONE you are playing
Th e SU STAI N PEDAL s e e ms t o w or k i n r e v e r se ?
• Power the keyboard down. With the SUSTAIN PEDAL plugged in to the SUSTAIN PEDAL INPUT
• power t he keyboard up. This will cause t he SL-SL-760 to sense t he proper polarity setting
• for the type of pedal you are using and adjust properly.
Th e WH EELS o r A FTERTOU CH d o n o t s e e m t o w or k ?
• Make sure they are enabled on the ZONE you are playing
• Make sure they are enabled in the Patch in your module you are sending to.
I am playing a ZONE that I know is on but nothing is happening?
• Make sure you are playing within the SPLIT range of notes set up for that ZONE
• Make sure that the MIDI channel is set correctly.
• Make sure the VOLUME PEDAL is depressed and all other volume setting are up.
TROUBL E SHOOTI NG
GU I D E
PROBLEM
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
PROBLEM
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
POSSI B LE SOL UTI ONS
