Controls & Features - PAX10+
1. LINE input : TRS jack socket suitable for use with
balanced or un-balanced line level signals as supplied
by the outputs of mixing consoles, CD players,
keyboards.
2. LINK socket : TRS jack socket wired in parallel with
the LINE input. This facility allows the linking of the
input signal to many PAX+ powered monitors.
3. VOLUME control : Sets the overall sound level of the
monitor. Too much volume can result in a distorted
sound, feedback or hearing damage. Always turn the
VOLUME control fully anti-clockwise before turning the
power on or off.
Features - PX10+
This is an extension (unpowered) loudspeaker cabinet for the
PAX10+. Use a suitable Jack to Jack speaker grade cable to
connect to the PAX10+. The socket to power the additional
monitor is located on the side panel of the PAX10+ and marked
EXTENSION SPEAKER. To avoid damage it is recommended
that only a PX10+ passive monitor should be used with a
PAX10+ powered monitor. However, other speaker cabinets can
be used providing they have the correct power rating and are 8
ohms impedance or above.
It is also recommended that the PX10+ only be used with the
PAX10+ although it can be used with other monitor systems and
amplifiers provided its power rating is not exceeded.
