Studiomaster XR-80 - Handheld Transmitter Features; Body Pack Features; Polar Pattern Transmitter; Frequency Response Curve Transmitter

3
1. It protects the capsule from damages. Also it acts as an effective wind & pop filter.Grill :
2. It is provided for synchronisation with receiver.IR Window:
LED screen displays the fixed channel frequency with channel number.3. LED Screen :
4. This switch can be used to ON/OFF microphone as required. Single press to switch ON thePower ON/OFF Switch:
Mic and long press to switch it OFF.
3.3 Body Pack Features
8
4
7
1
5
2
3
Lapel Microphone
9
1. Transmission Antenna.Antenna:
2. LED lights up when Lapel body is switched on.Power ON LED:
3. Input socket to connect lapel microphone.Mic Input:
4. It display fixed frequency with channel number.Display :
5. This switch can be used to ON/OFF microphone as required.Power ON/OFF Switch :
6. Use 2 x 1.5V AA batteries to power Bodypack unit.Battery Compartment:
7. Slide downward for access to the battery compartment.Battery Cover:
8. To hang on belt.Belt Clip:
9. Microphone (Lapel).
3.4 Polar Pattern Transmitter
673.00
180
CH
6
3.2 Handheld Transmitter Features
XR -80 H
IR
1
3
4
2
683.00
200
CH
683.00
200
CH
3.5 Frequency Response Curve Transmitter
