Stulz CRS 361 A - 4.3 Component Layout (AS Unit, Size S)

10
/04.2016/G35EN
4.3 Component layout
Internal layout of AS unit, size S
Fans (5)
Controller
Evaporator
Condensate drip tray
E-box
Electronic
expansion valve
Inverter
Compressor
Liquid receiver
Oil separator
Air filter
