11
M
INI-SPACE EC INSTALLATION, OPERATION AND MAINTENANCE MANUAL
Figure 6. Upfl ow Confi guration Typical Air Patterns
SUPPLY
AIR OUTLET
RETURN
AIR INLET
SUPPLY
AIR OUTLET
DUCT
RETURN
AIR INLET
REAR DUCTED RETURN
SUPPLY
AIR OUTLET
DUCT
RETURN
AIR INLET
FRONT FREE RETURN
DUCT
RETURN
AIR INLET
SUPPLY
AIR OUTLET
DUCT
TOP DUCTED DISCHARGE
TOP DISCHARGE WITH 2 OR 3 WAY PLENUM BOX
REAR DUCTED RETURNFRONT FREE RETURN
