E/0204/39/60
19. Options
19.1 ELECTRICAL REHEAT - RSC
This option is useful when heating of the internal air is required. The electrical reheat is made of
aluminium and includes a safety device. It is controlled directly by C1010 microprocessor, when
present (see Chapter 11: Control, Monitoring and Safety Components for heating logic). When
units are mechanically controlled, the required additional TMC thermostat, is included in the RSC
option.
19.2 MOUNTING KIT FOR OUTDOOR UNIT - MKITSO
This mounting kit for outdoor unit, consists of a pair of shelves, made of zinc plated steel sheet,
with plastic coating. In this kit are present also the necessary screw anchors to fix the shelves to
the shelter wall (suitable only to concrete or brick walls), screws and washers and anti-vibrating
supports to fix the motor-condensing unit to the shelves.
IMPORTANT NOTE IN CASE THE SHELVES ARE NOT
PROVIDED AS OPTION BY STULZ:
In any case, the support of the outdoor unit must not obstruct,
even partially, the air flow through the condenser coil, and
reduce the condenser coil efficiency this way.
1. screw anchor
2. nut
3. serrated lock washer
4. washer
5. anti-vibrating mount
6. washer
7. screw
A free space of > 250 mm between wall
and outdoor unit must be maintained at any
time !
