10INSTALLATIONHBASE STÛV16
2
.4 POSITIONING THE CUBE SHELL
Step 21 Use the cube handles to position
the shell on the stove.
Step 22 Align the cut-out in the shell
with the stove's flue.
Step 23 Secure the shell with the 4
screws in the front, starting with the lower
screws.
Step 20 Using the four connecting
brackets, M5x12 hex bolts and M5 nuts
supplied in the complementary enclosed
box, attach the stove and base plate
together on all sides (front, rear, left and
right).
CAUTION
The paint is fragile!
!
232221
2020
3
mm
x4
8mm8mm
