16
Hearth extension Extension de l’âtre
AB
S21/65H min 18" 31 7/8"
S21/75 min 18" 35 3/4"
S21/85 min 18" 39 3/4"
S21/95 min 18" 43 5/8"
S21/105 min 18" 47 5/8"
S21/125 min 18" 51 1/2"
S21/135 min 18" 55 1/2"
A
3 3/4"
B
Convection grills Grilles de convection
Note : La distance entre le plafond et le centre de la grille
de convection chaude doit être d’au moins 12’’. Il n’est pas
permis de raccorder 2 tuyaux ensemble, pour une distance
horizontale maximale de 10’. Il n’y a cependant pas de
limite en distance verticale.
Note: The distance between the ceiling and the center
of the hot convection grill must be at least 12». It is not
permitted to join 2 connect 2 flexible ducts as 10 feet is the
maximum horizontal length allowed. No length limit for
vertical length.
Glass / Vitre
