Style selections FHTS80021 - Assembly Instructions; Step-by-Step Assembly

ASSEMBLY INSTRUCTIONS
1.
Carefully place the top (2) upside down on a soft surface. Failure to do so
could result in damage or scratches to the tabletop. Attach the side panel B(4),
to the top (2). Use bolts (AA).
1
ATTENTION: Assembly is
easiest when you partially
tighten bolts at first. Only
tighten by hand.
2
ATTENTION: Assembly is
easiest when you partially
tighten bolts at first. Only
tighten by hand.
2. Attach the side panel A(3) to the top (2).
Use bolts (AA).
3
3. Attach the side panel C(5) to the leg of the side panel A(3) and side panel B(4).
Use bolts (BB).
4
4. Attach the tank base (7) to the side panel A(3) and side panel B(4) .
Use bolts (BB).
8
M6 x 15 mm Bolt
AA
Hardware Used
M6 x 25 mm Bolt
BB
Hardware Used
Hardware Used
M6 x 15 mm Bolt
AA
M6 x 25 mm Bolt
AA
Hardware Used
x 2
x 2
x 4
x 4
AA
4
2
4
3
AA
BB
4
3
5
BB
3
4
5
