ASSEMBLY INSTRUCTIONS
9
5.
Attach the side panel D(6) to the leg of side panel A(3).
Use bolt (CC) and washers (DD).
5
6
Attach the handle (FF) to the side panel D(6).
φ 17 Washer
DD
7
7. Place lava rocks (9) in the burner bowl.
6.
CC
Bolt
Hardware Used
x 1
x 2
3
4
5
6
CC
DD
DD
8
8. Place the lid (1) over the burner bowl.
9
FF
6
Hardware Used
Handle
FF
x 1
1
