Style selections TPGAZ9116D - Page 7

2.1. Insert short corner bar (I) into long corner bar (H). Repeat for remaining long corner bars (H) and
short corner bars (I).
2.2. Insert the bottom part of long corner bar (H) into top connector (G).
Reapeat for remaining long corner bars (H). Insert short corner (I) bar into corner panel (A).
I
I
A
A
A
A
H
H
H
I
B1
B1
B1
H
H
H
H
G
H
A
A
H
B1
G
INSTALLATION INSTRUCTIONS
2
