StyleWell WHEATON - Assembly - Part 1; Preparing the Sides for Assembly; Preparing the Bottom Shelf; Attaching the Sides

8
2
Locate the Bottom Shelf (A).
Insert the Wood Dowels (CC) into the pre-drilled
holes on the edges of the Bottom Shelf (A).
Preparing the bottom shelf for assembly
3
Align the previously installed cam lock screws from step 1 on
the Left and Right Side Panels (B, C) with the pre-drilled holes
on the Bottom Shelf (A) as shown in the diagram.
Place Cam Lock Connectors (BB) into the pre-drilled holes and
tighten with a Phillips screwdriver.
Attaching the sides
1
Locate the Left Side Panel (B) and the Right Side Panel (C).
Insert the Wood Dowels (CC) into the pre-drilled holes on
the edges of the Left and Right Side Panels (B, C).
Insert the Cam Lock Screws (AA) into the pre-drilled holes
on Left and Right Side Panels (B, C) where indicated.
Tighten using a Phillips screwdriver.
Preparing the sides for assembly
Assembly
B
A
C
A
CC
CC
BB
AA
B
C
