With the tires under proper pressure, place the valve stem at the bottom. Mark
the spot on the floor and with the rider’s weight on the bike, roll exactly one
wheel revolution in a straight line (until the valve comes around again to the
button). Mark where the valve stem is and measure the distance between the
two markers.
*3 Total Distance & Total Ride Time
Data would be deleted once you replace this device’s battery. In this case, you
could enter the total distance and time manually, so you don’t have to start from
nothing.
How to change setting?
In any stage, press and hold the MODE button for 3secs to enter into settings
menu.
Install the device on bike
Install the bracket and computer unit
Step 1: Attach the rubber slice on handlebar/stem.
Step 2: Stick the bracket on the handlebar/stem.
Step 3: Hang the O-ring on one side of the bracket. Go around the handle bar
or stem. After that, secure the O-ring to the other side of the bracket. For more
stability, you could fix the bracket using cable ties. Now, the bracket should be
properly installed. [refer to instructional video]
Step 4: Set the computer into the notch of the bracket (NW/SE direction), push
on gently and clockwise to fix the computer unit.
Note: You can loosen the four screws on the bracket to change its orientation.
Install the sensor and magnets
[Refer to Diagram 5]
Step 1: Install Speed Magnet
Installed the speed magnet on the bicycle spoke. Secure the magnet and
tighten the screw. Magnet should face towards the sensor.
Step 2: Install Sensor
Attach the rubber slice on the fork. Stick the sensor on it. When installing sensor,
the side marked with ‘sensor’ need to face towards the wheel direction and stay
close to the speed magnet. Then, use the straps to tighten it properly.
Step 3: Tighten the cable ties and cut off the excessive part of the ties.
EN-12
