Product Specifications
Specifications S670 (100Vac-120Vac Output) S670 (220Vac-240Vac Output)
Battery
Battery Material Lithium-ion Rechargeable Cell
Battery Voltage 14.4V
Battery Capacity 720Wh(14.4V/50000mAh, equivalent 3.6V/200000mAh)
AC Output
Continuous Output Power 500W 500W
Peak Output Power 1000W 1000W
Continuous Output Voltage 100Vac-120Vac 220Vac-240Vac
Continuous Frequency 60/50Hz 50Hz
Overload
5 0 5 W ≤ P L o a d < 6 0 0 W @ 2 M i n ;
600W ≤ PLoad < 650W @10s;
650W ≤ PLoad < 1000W@500ms;
50 5W ≤ P Lo ad < 6 00 W @ 2M in ;
600W ≤ PLoad < 650W @10s;
650W ≤ PLoad < 1000W@500ms;
13V (Car Charger Socket)
Output Voltage 13.0±0.3V 13.0±0.3V
Continuous Output Current 10A 10A
12V (DC Output)
Output Voltage 12V
12V
Continuous Output Power 10A 10A
USB Output
USB1&USB2 5V/3A,9V/2A,12V/1.5A QC3.0 (18W) 5V/3A,9V/2A,12V/1.5A QC3.0 (18W)
USB3&USB4 5V/3A 5V/3A
USB Type-C
5V/3A,9V/3A,12V/3A,15V/3A,20V/2.25A
(45W PD)
5V/3A,9V/3A,12V/3A,15V/3A,20V/2.25A(45W PD)
INPUT
Max Input Power 168W 168W
Input Voltage Range
12-45Vdc (Over-Voltage Protection
47V±1V)
12-45Vdc (Over-Voltage Protection 47V±1V)
Solar Charging Mode MPPT MPPT
Main Unit
Relative temperature 0-40°C
Relative humidity 10%-90%
Trouble-shooting
If your device can not be charged with this portable power supply, follow these steps:
1. Make sure the main power button is turned on.
2. Ensure the output port has been turned on. The green LED light indicating its state should be lit up.
3. Check the battery capacity display. If it's at 20% or below, you need to charge the portable power supply.
4. Verify your device is suitable to be charged with this product. All the output ports have their own Max
power capacity. Check them to ensure your device is compatible.
EN-07
Error
Code
Error Details Protection Condition Resume Condition
E01
Heatsink A over-temperature
protection
Heatsink temperature ≥ 75°C
(±2°C)
Heatsink temperature ≤ 70°C
(±2°C ), auto-resume
E02
Heatsink A low-temperature
protection
Heatsink temperature ≤ -18°C
(±2°C )
Heatsink temperature ≥ -8°C
(±2°C), auto-resume
E03 Battery malfunction protection
Voltage ≤ 8V (±0.2V) or battery
damage
Cannot charge
E04
Battery discharging over-
temperature protection
Battery pack temperature ≥ 63°C
(±2°C)
Battery pack temperature ≤ 55°C
(±2°C ), auto-resume
E05
Battery discharging low-
temperature protection
Battery pack temperature ≤ -18°C
(± 2°C )
Battery pack temperature ≥ -8°C
(±2°C ), auto-resume
E06
Battery charging over-temperature
protection
Battery pack temperature ≥ 48 °C
(±2°C)
Battery pack temperature ≤ 38°C
(±2°C ), auto-resume
E07
Battery charging low-temperature
protection
Battery pack temperature ≤ 2°C
(±2°C)
Battery pack temperature ≥ 12°C
(±2°C ), auto-resume
E08
Total voltage overvoltage
protection
Battery voltage ≥ 17.2V (±0.2V)
Discharge, voltage ≤ 16.6V(±0.2V),
auto-resume
E09
Total voltage low-voltage
protection
Battery voltage ≤ 12.8V (±0.2V)
Charge, voltage ≥ 14V(±0.2V),
auto-resume
E18 PV input overvoltage protection PV voltage ≥ 47V (±1V)
PV voltage ≤ 40V(±1V), auto-
resume
E20 PV input overcurrent protection PV current ≥ 10A (±1A) Remove PV charging to resume
E24 PD/QC short-circuit protection PD or QC output short circuit
Remove the load and restart the
USB output
E26 DC12V output overload protection
DC12V with load power exceeds
130W
Remove the load and restart the
DC output
E29 DC13V output overload protection
DC13V with load power exceeds
145W
Remove the load and restart the
DC output
E34 System overload protection
System with load power exceeds
560W and turn off DC
Remove the load and restart the
DC output
E36 Inverter output overload protection Inverter output overload
Remove the load and restart the AC
output
E37
Inverter output overcurrent
protection
Inverter overload or short circuit
Remove the load and restart the AC
output
E38 System overload protection
System with load power exceeds
560W and turn off AC
Remove the load and restart the AC
output
E39
Heatsink B over-temperature
protection
Heatsink temperature ≥ 75°C
(±2°C)
Heatsink temperature ≤ 70°C
(±2°C ), auto-resume
E40
Heatsink B low-temperature
protection
Heatsink temperature ≤ -18°C
(±2°C )
Heatsink temperature ≥ -8°C
(±2°C), auto-resume
Note:
1. The setting numbers above are theoretical numbers. There will a slight deviation between the actual
numbers and the theoretical numbers. This is a normal phenomenon.
2. When the battery is low-voltage, the power indicator icon on the LCD screen flashes. At this time, the
product needs to be charged. When the battery voltage is higher than 13.4V, the power indicator icon
stops flashing.
EN-08
