Planning Information
Undercounter Model 249R
Dimensions in parentheses are in
millimeters unless otherwise specified.
3
INSTALLATION SPECIFICATIONS
DIMENSIONS
Finished Rough Opening Width 24" (610)
Finished Rough Opening Height 34
1
/2" (876)
F
inished Rough Opening Depth 24" (610)
Location of Electrical Within shaded area
See Installation Instructions shipped with unit for detailed specifications.
34
1
/2"
(
876)
ROUGH
OPENING
HEIGHT
24"(
610)
R
OUGH OPENING
W
IDTH
10
1
/2" (267)
7"
(178)
7"
(
178)
E
8
1
/2"
(216)
24"
(
610)
ROUGH
OPENING
D
EPTH
TOP VIEW
FRONT VIEW
LOCATE ELECTRICAL
WITHIN SHADED AREA
